| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 26.5645 |
| Cartridge type | Desiccant Cartridge |
| Cut-out pressure | 174 psi |
| Exhaust | JED-463-1 |
| Heating System | Yes |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Max. operating pressure | 188.5 psi |
| Opening pressure | 210.31 psi |
| Operational range | 21.76 psi |
| Port thread 11 | M22 x 1.5 JED - 388 - 3 |
| Port thread 12 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 JED - 388-3 |
| Port thread 22 | Tire inflation device M16 x 1.5 |
| Port thread 3 | JED-463-1 |
| Port thread 4/23 | 1/4" - 18 NPTF |
| Silencer | No (432 407 012 0 retrofittable) |
| Solenoid connection | Bayonet DIN 72585-A1-2.1-1-Sn/K1 |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Unloader | Yes |
| Voltage | 24 V |
