| SINOTRUK (CNHTC) | WG9700240035/1 |
| SINOTRUK (CNHTC) | WG97002400351 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 5.9305 |
| Distance between holes | 6.14 in |
| Electrical connection | 2x Bayonet DIN 72585 A1-7.1 / A1-2.1 |
| Max. operating pressure | 123.28 psi |
| Mounting | 4x Ø 9 mm |
| Output force | 1573.66 lbf |
| Port thread 1 | M16 x 1.5 JED-388-0 |
| Protection class | IP 33 |
| Rated current connector | 1.5 A |
| Rated current sensor (A) | 0.09 A |
| Rated current solenoid valve (A) | 1.60 A |
| Stroke | 2.74 in |
| Technical specification | OE specification |
| Temperature range | -30°C to +90°C |
| Voltage | 12/24 V |
