WABCO威伯科EBS挂车模块4802040020 3454403480 34544 03480 P34544 03480 1601034 1315695 4103223 A0004319413 S4780E0070 597107K000 59710 7K000 41211417 1482401911 41211417 41032232 4103223 1601034 81523016208
EBS挂车模块 -- 4802040020
产品介绍
| DAEWOO | 3454403480 |
| DAEWOO | 34544 03480 |
| DAEWOO | P34544 03480 |
| DAF | 1601034 |
| DAF | 1315695 |
| DAF | 4103223 |
| EVOBUS | A0004319413 |
| HINO | S4780E0070 |
| HYUNDAI | 597107K000 |
| HYUNDAI | 59710 7K000 |
| IRISBUS | 41211417 |
| ISUZU | 1482401911 |
| IVECO | 41211417 |
| IVECO | 41032232 |
| IVECO | 4103223 |
| LEYLAND DAF | 1601034 |
| MAN | 81523016208 |
| MAN | 81923016216 |
| MAN | 4103223 |
| MERCEDES-BENZ | 0004319413 |
| MERCEDES-BENZ | A0004319413 |
| MERCEDES-BENZ | 4103223 |
| NEOPLAN | 81523016208 |
| PACCAR | 1601034 |
| SCANIA | 1935136 |
| SCHMITZ CARGOBULL | 1042024 |
| SCHWARZMÜLLER | 97456 |
| SHAANXI | DZ95259364002 |
| SOLARIS | 1102219001 |
| UD TRUCKS | 4528900Z05 |
| VAN HOOL | 11167595 |
| VDL | 297659 |
| VDL | 20297659 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 5.4134 |
| Delivered pressure | 123 psi |
| Distance between bolts | 3.15x3.15 in |
| Electrical connection | Bayonet DIN 72585 |
| Max. operating pressure | 123.28 psi |
| Mounting | 3x M8 |
| Port thread 11 | M22 x 1.5 JED - 388-4 |
| Port thread 21 | M22 x 1.5 JED - 388-0 |
| Port thread 22 | M22 x 1.5 JED - 388-0 |
| Port thread 3 | Integrated Silencer |
| Port thread 42 | M16 x 1.5 JED-388-0 |
| Port thread 43 | M16 x 1.5 JED-388-0 |
| Protection class | IP 6K6K, IP 6K9K |
| Rated current | 1400 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
